TD-4420DN high-quality network desktop label printer
Print high-quality, continuous labels using media up to 118mm/4.65 inch wide. With built-in network for easy sharing.Product Details
- Network connectivity
- High-quality up to 203dpi print resolution
- Fast print speeds up to 8 inches per second
- Print width up to 4.09 inches / 104mm
- Easy set-up with automatic media configuration
- Ready to integrate with iOS and Android apps
Product Overview
With built-in network connectivity, the TD-4420DN is designed to be shared.
Labels are printed at a high-resolution, producing sharp and clear images. Making the TD-4420DN ideal for printing 1D barcodes for scanning.
Direct thermal print technology produces accurate images, with crisp definition. Utilising heat-sensitive coating, ink is not required. A good choice for printing high-volume, temporary labels with barcodes with a maximum media width up to 118mm/4.65 inches wide.
Related Products
-
The BDE-1J000102-102 continuous label roll, measuring 102mm wide and 58m in length, has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£144.00Inc. VAT£120.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J026051-060 die-cut label roll, measuring 51mm x 26mm and containing 500 labels per roll has been Certified by Brother International Europe. Each purchase contains 12 rolls per order.£39.60Inc. VAT£33.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J026051-102 die-cut label roll, measuring 51mm x 26mm and containing 1,900 labels per roll has been Certified by Brother International Europe. Each purchase contains 16 rolls per order.£144.00Inc. VAT£120.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J026076-102 die-cut label roll, measuring 76mm x 26mm and containing 1,900 labels per roll has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£120.00Inc. VAT£100.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J044076-066 die-cut label roll, measuring 76mm x 44mm and containing 400 labels per roll has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£48.00Inc. VAT£40.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J050102-102 die-cut label roll, measuring 102mm x 50mm and containing 1,050 labels per roll has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£124.80Inc. VAT£104.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J152102-058 die-cut label roll, measuring 102mm x 152mm and containing 85 labels per roll has been Certified by Brother International Europe. Each purchase contains 20 rolls per order.£120.00Inc. VAT£100.00Ex. VATThis product is available from our authorised retailers
-
The BDE-1J152102-102 die-cut label roll, measuring 102mm x 152mm and containing 350 labels per roll has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£158.40Inc. VAT£132.00Ex. VATThis product is available from our authorised retailers
-
The BDL-7J000058-040 continuous receipt roll, measuring 58mm in width, has been Certified by Brother International Europe. Each purchase contains 24 rolls per order.£72.00Inc. VAT£60.00Ex. VATThis product is available from our authorised retailers
-
The BDL-7J000058-102 continuous receipt roll, measuring 58mm in width, has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£83.90Inc. VAT£69.92Ex. VATThis product is available from our authorised retailers
-
The BDL-7J000076-066 continuous receipt roll, measuring 76mm in width, has been Certified by Brother International Europe. Each purchase contains 8 rolls per order.£43.20Inc. VAT£36.00Ex. VATThis product is available from our authorised retailers
-
The BDL-7J000102-058 continuous receipt roll, measuring 101.6mm in width, has been Certified by Brother International Europe. Each purchase contains 20 rolls per order.£120.00Inc. VAT£100.00Ex. VATThis product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
This product is available from our authorised retailers
-
Label cutter for the TD-4D series label, receipt and wristband printers.£107.18Inc. VAT£89.32Ex. VATThis product is available from our authorised retailers
-
Thermal Print Head (203dpi) for the TD-4410D and TD-4420DN label printers£119.06Inc. VAT£99.22Ex. VATThis product is available from our authorised retailers
-
Label Peeler for the Brother TD-4D series label, receipt and wristband printers£49.63Inc. VAT£41.36Ex. VATThis product is available from our authorised retailers
-
Platen Roller (203dpi) for the TD-4410D and TD-4420DN label printers£20.06Inc. VAT£16.72Ex. VATThis product is available from our authorised retailers
-
Tablet holder for the TD-4D series label, receipt and wristband printers.This product is available from our authorised retailers
Specifications
General
| Technology | Direct thermal |
| Buttons | Power , Feed |
| LED | Status |
| Memory capacity | RAM, FLASH, 64MB, 256MB |
Connectivity
| Serial | Yes |
| USB interface | USB 2.0 Full Speed |
| Wired network interface | 10/100 BASE-TX |
Dimensions and weights
| Dimensions | 180mm (W) x 224mm (D) x 155mm (H) |
| Weight | 2.08 |
In the box
| In the box | Quick Setup Guide (QSG), Printer, AC adaptor, AC Power supply cord, Warranty Card |
Operating systems & software
| Supported Operating Systems | Windows (Windows 8.1, Labelling,SupportedOperatingSystems,Windows, Labelling,SupportedOperatingSystems,Windows, Labelling,SupportedOperatingSystems,Windows, Labelling,SupportedOperatingSystems,Windows), Android (4.0.3 or higher), iOS (8 or higher), For the full list of compatible operating systems visit support.brother.com, Linux |
Printing
| One Dimensional Barcode Symbology | Code128, Code39, EAN13(JAN13), EAN8(JAN8), UPC-A, UPC-E, UPC/EAN EXTENSION, CODABAR(NW7), POSTNET, MSI, GS1-128(UCC/EAN-128), ITF(I-2/5), Intelligent Mail Barcode, GS1 Databar(Omnidirectional/Truncated/Stacked/Stacked Omnidirectional/Limited/Expanded/Expanded Stacked) |
| Two Dimensional Barcode Symbology | DataMatrix, Aztec, PDF417, QR Code |
| Printing Maximum Print Speed | 8 ips |
| Printing Resident Fonts | Letter Gothic Bold, Gothic, Brougham, Brussels, Helsinki, San Diego |
| Resolution (dpi) | 203 |
| Printing Maximum Roll Diameter | 127mm |
| Printing Minimum Label Width | 19mm |
| Printing Minimum Roll Core Diameter | 12.7mm |
| Supported commands | P-touch Template, ZPL 2 emulation, CPCL emulation, ESC/P, EPL2, DPL |
Solutions
| SDK (Software Development Kit) | Yes |
Software Security Updates Guarantee
Brother devices conform to The Product Security and Telecommunications Infrastructure (Security Requirements for Relevant Connectable Products) Regulations 2023 and receive guaranteed software security updates until at least five years after the device is last in production.
After the initial support period, Brother shall use all reasonable endeavours to provide software updates for as long as reasonably practicable.
If you already own a Brother device, visit support.brother.com for information specific to your device.
Software support
Brother provides the tools for developers to integrate their printing applications. Printer drivers are available for Windows Operating Systems. Software Development Kits are available to embed label printing into existing software programs. Software development kit's available from: https://atyourside.brother.co.uk/developer-centre
Print from your Windows PC
Custom labels are easily created using Brother's P-touch Editor. Add your company logo, symbols to hundreds of built-in images to the labels you create. Not to mention, linking your excel data to print large batches of labels.
Network connectivity
Increase your teams productivity with this network desktop label printer. Sharing is made easier with the integrated network port.Seamless integration
Understanding that integration into legacy systems is important, many printer command languages are supported. Including ZPL II emulation, Raster, CPCL emulation and many more.
